Precision Blade for Glass Fiber and Fiberglass Processing
This 178 × 15.7 × 0.9 mm glass fiber cutting blade for fiberglass processing is precision-ground for the equipment interface. Standard and custom formats can be matched to the holder, fiber presentation, material grade, hardness, bevel and finish defined by the approved specification.
Product Specifications
MEIRENTE glass fiber cutting blades are precision-ground straight knives for stable cutting of glass fiber, fiberglass, chemical fiber, and related industrial fiber materials. Multiple standard lengths, widths, and thicknesses are available for different cutter assemblies and production requirements.
| Item | Specification |
|---|---|
| Product Type | Glass fiber cutting blade / fiberglass processing knife / chemical fiber cutter blade |
| Material Options | High-speed steel, tool steel, stainless steel, tungsten carbide, and application-specific grades |
| Standard Length Range | 85–244 mm |
| Standard Width Range | 8–15.7 mm |
| Standard Thickness Range | 0.3–0.9 mm |
| Surface Finish | Precision-ground |
| Cutting Edge | Straight precision-ground bevel; edge geometry confirmed according to the approved drawing and application |
| Application | Glass fiber rovings, fiberglass production, chemical and synthetic fibers, staple fiber cutting, and industrial fiber processing equipment |
| Customization | Custom length, width, thickness, material, hardness, bevel, surface finish, and coating are available according to drawings or samples |
| OEM / ODM | Supported |
| MOQ | Flexible; confirmed according to specification, material, and order quantity |
Standard Sizes & Dimensions
| Length (mm) | Width (mm) | Thickness (mm) | Specification |
|---|---|---|---|
| 85 | 10 | 0.9 | 85 × 10 × 0.9 |
| 93 | 10 | 0.5 | 93 × 10 × 0.5 |
| 135 | 8 | 0.3 | 135 × 8 × 0.3 |
| 151 | 10 | 0.5 | 151 × 10 × 0.5 |
| 178 | 15.7 | 0.9 | 178 × 15.7 × 0.9 |
| 206 | 12 | 0.5 | 206 × 12 × 0.5 |
| 210 | 10 | 0.5 | 210 × 10 × 0.5 |
| 225 | 10 | 0.5 | 225 × 10 × 0.5 |
| 244 | 10 | 0.5 | 244 × 10 × 0.5 |
Customization & Quality Control
| Available Sizes | 85 × 10 × 0.9; 93 × 10 × 0.5; 135 × 8 × 0.3; 151 × 10 × 0.5; 178 × 15.7 × 0.9; 206 × 12 × 0.5; 210 × 10 × 0.5; 225 × 10 × 0.5; 244 × 10 × 0.5 mm |
|---|---|
| Inspection | Length, width, thickness, straightness, flatness, surface finish, and cutting edge are inspected before shipment |
| Service | Drawing- and sample-based custom manufacturing |
Buyer Terminology and Blade Specifications
Industrial teams often use several names for the same blade family. We use those terms to identify the likely application, then confirm the final design from the drawing, sample and machine conditions.
Size and geometry. The terms “precision-ground glass fiber knife”, “thin fiberglass cutting blade” and “straight fiber cutter knife” usually describe geometry or configuration. Requests using “notched glass fiber blade” or “replacement fiberglass machine blade” should confirm critical dimensions and edge orientation.
Application and equipment. Buyers may search for “precision knife for glass fiber cutting equipment”, “fiberglass cutter replacement blade” or “glass fiber processing machine knife” when identifying an application. For requests described as “textile glass fiber cutting knife” or “precision-ground fiber cutter blade”, include the processed material, machine interface and required cut quality.
Custom and replacement supply. Sourcing language can include “custom glass fiber cutter blade”, “custom blade for fiberglass equipment” or “OEM glass fiber blade from drawing”. Requests using “drawing-based fiberglass cutting knife” or “glass fiber knife manufacturer” should include an approved drawing or sample details before production.
The approved drawing and application conditions always control the manufactured blade specification.
Glass Fiber Cutter Blade Specifications
- Confirm length, width, thickness, notches, holes and the holder interface.
- Describe the glass fiber form, feed condition and required cutting result.
- State material, hardness, bevel and surface-finish requirements if already approved.
- Report wear, chipping, fiber pull or cut-consistency issues from the existing blade.
Compare related fiberglass & glass fiber cutting blades, or review the custom industrial knife manufacturing process before sending your drawing, sample details and required quantity.
Direct answers for blade buyers
Questions Buyers Ask About This Blade
What is Glass Fiber Cutting Blade used for?
This 178 × 15.7 × 0.9 mm glass fiber cutting blade for fiberglass processing is precision-ground for the equipment interface. Standard and custom formats can be matched to the holder, fiber presentation, material grade, hardness, bevel and finish defined by the approved specification.
What information is needed to quote Glass Fiber Cutting Blade?
Please provide confirm length, width, thickness, notches, holes and the holder interface.; describe the glass fiber form, feed condition and required cutting result.; state material, hardness, bevel and surface-finish requirements if already approved.. Include the required quantity and any current cutting problem when available.
Can MEIRENTE manufacture a replacement blade from a drawing or sample?
Yes. MEIRENTE reviews drawing- or sample-based replacement blade requests. Critical dimensions, mounting features, cutting direction, material and edge requirements are confirmed before production.
How is the final industrial blade specification confirmed?
The approved drawing and confirmed application conditions control the final specification. The workpiece, machine interface, cutting motion, current defect and inspection requirements should be reviewed together rather than selecting a blade from its name alone.
